Bigger clamping range than one ear clamp
Two ears can compensate for changes in diameter due to thermal expansion &shrinkage or vibration conditions.
Provide uniform and adjustable surface pressure.
Bolt-free, compact one-piece ear clip provide simple, fast and secure installation
| K-Seal Code | Diameter range (mm) | Bandwidth*Thickness(mm) |
| KDE07009 | 7--9 | 7×0.7 |
| KDE07011 | 9--11 | 7×0.9 |
| KDE07013 | 11--13 | 7×1.0 |
| KDE07515 | 13--15 | 7.5×1.0 |
| KDE07518 | 15--18 | 7.5×1.2 |
| KDE07520 | 17--20 | 7.5×1.2 |
| KDE09023 | 20--23 | 9×1.3 |
| KDE09025 | 21--25 | 9×1.3 |
| K-Seal Code | Diameter range (mm) | Bandwidth*Thickness(mm) |
| KDE09027 | 23--27 | 9×1.4 |
| KDE09028 | 25--28 | 9×1.4 |
| KDE09531 | 28--31 | 9.5×1.4 |
| KDE09534 | 31--34 | 9.5×1.4 |
| KDE09537 | 34--37 | 9.5×1.5 |
| KDE10040 | 37--40 | 10×1.6 |
| KDE10043 | 40--43 | 10×1.6 |
| KDE10046 | 43--46 | 10×1.6 |
